Fitment Guide
Wheel Hub Bores (Centerbore)
Great question. Check out our The Source blog post on this exact topic and why it makes a big difference in wheel/hub fitment.
We made this part easy for you. As long as you know what your vehicle fitment is, the standardized hub bore will also fit your vehicle.
For example: If you know your UTV fitment is a 4x156 bolt pattern, all Valor Offroad wheels with a 4x156 will fit your vehicle because all have the same 132mm hub bore.
Select Vehicle Make
- All modern and full sized Polaris ATVs and UTVs with 4-lug bolt pattern are 4x156
- RZR Pro R/Turbo R, Xpedition, and Ranger XD 1500 are 5x114.3 (5x4.5)
- Turbo R, Pro R, Pro S: V12X150B-KIT5
- Xpedition: V12X150B-KIT5
- Ranger 1500: V12X150B-KIT5
- XP Pro: V12X150B-KIT
- Turbo, Turbo S: V12X150B-KIT
- XP1000: V12X150B-KIT
- Sportsman XP 850, 550: V10X125B-KIT
- Ranger, RZR 800/90: V38B-KIT
- Sportsman (Non-XP): V38B-KIT
- All UTV Pre 2015: V38B-KIT
- Maverick R: V12X150B-KIT6
- Maverick X3: V12X150B-KIT
- Defender: V10X125B-KIT
- Commander: V10X125B-KIT
- All non-sport ATVs and UTVs are 4x110 with the exception of the Pioneer 1000 and Talon, which are 4x137 bolt pattern.
- Honda Big Red, Pioneer: V12X150B-KIT
- Talon: V12X150B-KIT
- All other models: V10X125B-KIT
- ATV's with a Solid Rear Axle (SRA) use 4x137 bolt pattern.
- KRX 1000 uses a 4x156 bolt pattern
- ATV's with Independent Rear Suspension use 4x110 bolt pattern.
- Mule and Teryx's use a 4x137 bolt pattern with a 12mm stud.
- Mule PRO-FXT's use a 4x156 bolt pattern.
- Kawasaki Ridge is a 4x156 bolt pattern.
- KRX: V12X125B-KIT
- Ridge: V12X125B-KIT
- Teryx: V12X125B-KIT
- Mule: V12X125B-KIT
- Brute Force 750i / 650i: V10X125B-KIT
- All models use a 5x114.3 bolt pattern
- U10 Pro: V12X125B-KIT
- U10 Pro XL: V12X125B-KIT
- Z10: V12X125B-KIT
- Z10-4 Pro: V12X125B-KIT
- Villain: V12X125B-KIT
- Super Villain: V12X125B-KIT
- YXZ uses 4x156 bolt pattern
- Wolverine '15-'17 uses 4x110 bolt pattern
- Wolverine '18+ uses 4x156 bolt pattern
- Wolverine: V12X125B-KIT
- YXZ: V12X125B-KIT
- All other models: V10X125B-KIT
- All modern full-sized ATVs and UTVs are 4x115
- Wildcat XX: V12X150B-KIT
- All models use a 4x110 bolt pattern
- All models use a 4x156 bolt pattern
- 550i and 850i use a 4x137 bolt pattern
- All Speed vehicles are 4x156
- Baja Bandit: V12X150B-KIT
- El Diablo: V12X150B-KIT
- El Jefe: V12X150B-KIT
Hmmm I didn't see my make/model
Have an older UTV/ATV?
This fitment guide is intended for units sold in the last 5 years. If you didn't find your specific model listed above, give us a call so we can discuss your unique application.
