Select Vehicle Make
Wheel Fitments:
- All modern and full sized ATVs and UTVs with 4-lug bolt pattern are 4x156
- 2022+ Pro R and Turbo R are 5x114.3 (5x4.5)
Installation Kits:
- Turbo R, Pro R: V12X150B-KIT5
- XP Pro: V12X150B-KIT
- Turbo, Turbo S: V12X150B-KIT
- XP1000: V12X150B-KIT
- Sportsman XP 850, 550: V10X125B-KIT
- Ranger, RZR 800/90: V38B-KIT
- Sportsman (Non-XP): V38B-KIT
- All UTV Pre 2015: V38B-KIT
Wheel Fitments:
- All modern and full sized ATVs and UTVs are 4x137
Installation Kits:
- X3: V12X150B-KIT
- Maverick: V10X125B-KIT
- Commander: V10X125B-KIT
Wheel Fitments:
- All non-sport ATVs and UTVs are 4x110 with the exception of the Pioneer 1000 and Talon which are 4x137 bolt pattern.
Installation Kits:
- Honda Big Red, Pioneer: V12X150B-KIT
- Talon: V12X150B-KIT
- All other models: V10X125B-KIT
Wheel Fitments:
- ATV's with a Solid Rear Axle (SRA) use 4x137 bolt pattern.
- KRX 1000 uses a 4x156 bolt pattern
- ATV's with Independent Rear Suspension use 4x110 bolt pattern.
- Mule and Teryx's use a 4x137 bolt pattern with a 12mm stud.
- Mule PRO-FXT's use a 4x156 bolt pattern.
Installation Kits:
- Teryx, Mule, KRX: V12X125B-KIT
- Brute Force 750i, 650i: V10X125B-KIT
Wheel Fitments:
- All non-sport and modern ATVs & UTVs use a 4x110 bolt pattern, with the exception of the 2019+ YXZ, which uses a 4x156 bolt pattern.
Installation Kits:
- YXZ: V12X125B-KIT
- All other models: V10X125B-KIT
Wheel Fitments:
- Havoc and Stampede are 4x137 bolt pattern
- Wildcat XX is a 4x156 bolt pattern
Wheel Fitments:
- All modern full sized ATVs and UTVs are 4x115
Installation Kits:
- Wildcat XX: V12X150B-KIT
Wheel Fitments:
- All models use a 4x110 bolt pattern
Wheel Fitments:
- All models use a 4x110 bolt pattern
Wheel Fitments:
- All models use a 4x156 bolt pattern
Wheel Fitments:
- 550i and 850i use a 4x137 bolt pattern
Hmmm I didn't see my make/model
Have an older UTV/ATV?
This fitment guide is intended for units sold in the last 5 years. If you didn't find your specific model listed above, give us a call so we can discuss your unique application.
